Sol-XT™High Performance Low-E Coated Glass

Energy efficient laminated glass combined with a unique solar control interlayer and durable hard coat low-E glass

Overview

SOL-XT™ is a high performance energy efficient laminated glass combining a unique solar control interlayer with a hard coat low-E glass. The laminated interlayer itself utilises a solar absorbing technology designed to improve solar heat gain performance whilst maintaining high visible light transmission as compared to ordinary clear and laminated glass made with standard interlayers.

21.52mm Sol-XT Light 52 LowE Toughened Laminatedpaginate-filter-pictureNational Glass
  • Providing exceptional solar and thermal control with less sacrifice of natural daylight transmission;
  • Reduces summer heat gain and winter heat loss when compared to ordinary clear glass;
  • Depending on climate region and energy requirements, offers a broad range of solar and thermal control.

Residential and commercial glazing

  • SOL-XT™ series is broadly available in two ranges;
  • High visible light transmission (VLT%) with mid to high SHGC performance - using Light and Neutral colour tone glass option in an IGU provides VLT% between 65-58% and SHGC 0.44-0.34 respectively;
  • Mid to lower VLT% with low SHGC – using Grey, Green and Blue tones in an IGU with VLT% between 45-23% and SHGC 0.28-0.20.
  • Glass thickness range 8.76mm to 13.52mm single laminated and IGU. Other thicknesses and sizes on application.

When compared to ordinary non coated clear glass, Low-E glass can introduce some added complexities in relation to selection of glass types, manufacture and installation. For more information (Download)

  • Select either SOL-XT™ Light, Neutral, Grey, Green or Blue Low-E coated glass range;
  • Select appropriate thickness and process;
  • Single laminated or IGU and/or tempered laminated and toughened heat soaked laminated;
  • All glass to be selected and installed in accordance but not exclusively to the following Australian Standards;

AS 1288 Glass in buildings – Selection and installation

AS 2208 Safety glazing materials in buildings

AS 4666 Insulating glass units

AS/NZS 4667 Quality requirements for cut-to-size and processed glass

AS 1170 Wind & Structural Design Actions
